Model Number
|
ACS-3000
|
|
Lifting Capacity
|
3000kg
|
|
Lifting Height
|
1000mm
|
|
Min. Height
|
110mm
|
|
Lifting Time
|
50s
|
|
Platform Length
|
1400mm
|
|
Motor Power
|
220v/1phase
|
|
Air Pressure
|
0.6-0.8MPa
|
|
Machine Weight
|
410kg
|
1. The lifting platform extension, according to the different models for the vehicle support the ramp and extension, flexible use, cover small space.
2. Pneumatic release, safe and reliable.
3. The initial height is lower(110mm), have sliding ramp and extension.
4. Adopt axis drive, synchronization performance good, lifting capacity well.
5. Hydraulic system adopted imported electromagnetic valve and seal components, ensure the stability and working life of the machine.
6. When the power supply is off, lift and vehicle can be down by manual.
7. Rising and falling have safety alarm device.
8. Oil cylinder with upper return oil, prevent oil cylinder rust.
