Features

●Integration of advanced control technology and environmental concepts Cleaning, test and simulation of Automotive injectors.

●Multifunctionality: Direct flush, Reverse flush, Ultrasonic cleaning, On-vehicle cleaning, Spray test,Equilibrium test,Leakage test, Flow test, Automotive cleaning-test function.

●Test 6 injectors in one time

●Injector fuel distribution and delivery checking;

●Multilanguage applicable including English+Arabic

●LED display with clear menu and easy operation;

●Wide models can be tested with stable performance and reliable data;

●Liquid in tube drain back to tank automatically;

●Separated ultrasonic bath(Installed in cabinet);

●Optional:Special adapter for MONO & Side-feed injector;

●Packed inside dolly when shipped,CBM save



Specifications

Power supply: AC220V/110V ±10%,50/60Hz;

Input power: 250W;

Ultrasonic cleaner power: 100W,25KHz;

Simulated RPM range: 10000rpm; step: 50rpm;

Injection time: 0~600sec, step 1sec

Time range: 10000s(adjustable)

Pulse width: 0-20ms; step 0.1 ms;

Test liquid tank volume: 4L

Testing tube volume: 120ml

Dimensions:Carton 62*53*74cm=0.243cbm

G.W.:45kg
